EECP uses a computer system to control the inflation and deflation of compression belts wrapped around the patient's calves, thighs, buttocks and arms. The compression band is inflated in a three-level sequence from the distal end to the proximal end at the beginning of the heart's diastole, and deflated simultaneously at the end of diastole before the heart begins to contract. Inflation and deflation will be synchronized with the patient's ECG signals, increasing coronary perfusion pressure and venous return to the right heart (increasing preload and cardiac output); while the rapid and synchronous deflation of the cuff can reduce systemic vascular resistance , afterload and cardiac workload. Through outpatient treatment, the treatment course is 7 weeks, 5 times a week, 1 hour each time. As cardiovascular function improves, circulation in major organs throughout the body, including the brain, nervous system, kidneys, and genitourinary system, also improves.

At present, EECP adopts a stand-alone structure, which results in the use of the equipment being operated within a single department and can not cross departments or regions, let alone units that need personal data to be portable. HJ EECP system can combine the treatment data is uploaded to the cloud to achieve the goals of resource sharing, case management, and precise health promotion.Features of HJ EECP Therapy System:
1. Unique single pneumatic delivery design monitors and adjusts pressure to provide stable and comfortable treatment pressure.
2. The ECG and SpO2 waveform processing logic that meets clinical requirements, and the proprietary D/S Peak and Area index calculation method, summarize the treatment results and provide objective treatment data.
3. The entire treatment record is saved locally and in the cloud for subsequent analysis.
4. Unique arm compression design, more suitable for patients recovering from cerebral ischemia treatment.
5. The easy-to-operate user interface avoids operational errors and integrates treatment data on a single screen for easy interpretation by operators and doctors.
